Product Name | Professional Veterinary intensive care unit | Control Panel | 8.4”,171mmw×128mmH |
Model Number | EC-13 | Screen Type | Resistive |
Dimension | 1509mmW×884mmD×1899mmH (59.5”W×35”D×75”H) | Max. Power Consumption | 1.3KW |
Weight | Approximate 300kg(6601bs) | Average Power Consumption | 0.5KW |
Power Supply | AC100～120V /220～240V 50/60Hz(Grounded) | Power Supply Failure Protection | Emergency Ventilation Port |
Environment control | 4 Compartments Controlled Separately Cooling and Heating. Two Medium Compartments on top tier,one large compartment on bottom tier which could be divided into two medium compartment when needed | Negative on Generator | 7.2x106pcs/cm Negative lon Generator |
Air Purification | ultra violet sterilization ,high concentration negative lon Air purification | Accessories | Soda Lime CO, Absorption Powder,Equipment Mount Grid, Door Shade Curtain. |
Working Condition | -10～40℃(Indoor) | Built-in Printer | Smart Control Needle Type Printer |
Temperature Setting Range | 15～38°℃, Tolerance at 0.5℃ | UItra-violet Sterilization | 253nm UV Sterilization |
Oxygen Concen- tration Setting | 21～65%,Tolerance at±1%. | Blue Light Therapy | 415nm Blue Therapeutic Light Treatment |
Carbon Dioxide Monitoring and Removal | 200 -5000PPM Tolerance at ±10PPM,Built-in COz Sensor and Remover | Medical Nebulizer | ≥0.2ml/min, particle size:0.5 -2um, noise≤ 40dB(A) |
Alarms | O2 Concentration Alarm, Tempe-rature Alarm, Sensor Alarm, DoorOpening Alarm,CO2 ConcentrationAlarm, Emergency Ventilation PortMalfunction Alarms | LED lllumination | Pure White Cold Light for Examina-tion, 10 Stage Adjustable YellowComfort Light for lllumination |
Dehumidification | Automatic Dehumidification,High/Middle/Low Three Stages,High:45%~50%,Middle:40%~44%,Low: 30%~39%. | Ventilation Fan Control | Low/Middle/High, Three-StageSpeed Control.Defaults: Oxygen Input On: Low Speed.Temperature Control: High SpeedEmergency Port Open: High SpeedUltra-violet Sterilization On: MiddleCOz Concentration Level Alarm On:High |
